Tee 2'' socket weld 316L cl.3000
Regular price:
Regular price:
product unavailable
add to wish list
Description
Tee 2'' socket weld 316L cl.3000
- size: 2''
- fits pipe 2'' : 60,3mm DN50
- material: stainless steel 316/316L (X2CrNiMo17-12-2 / 1.4404)
- pressure class: 3000lbs (206bar)
- high pressure tee
- well weldable steel (praised by welders)
- equal-pass tee
- applications: boilers, high-pressure installations, high-temperature installations, refineries, marine industry
- 3.1 certificate on request (free of charge)
- origin: European Union
B = 2" (61,2-61,7mm)
Other name: Tee 2" socket weld 316 cl.3000 SW socket weld tee slip-on with keyway with thick wall tee stainless steel equal-pass tee socket fitting for welding
Information
Tee 2'' socket weld 316L cl.3000 belongs to the group of Socket Weld SW where the pipe is welded in the socket (inlet). Socket welded with a pipe form tight structure of the system. Socket Weld (SW) system ensures safety, durability and resistance to rupture of the system. Such welding is well praised by the welders. During welding, the pipe is inserted into the socket and does not move what ensures better freedom. The weld resists bigger pressures. SW fittings allow easy selection of the pressure of the system. Each fitting is stamped with size, grade, melt and pressure rating. All SW fittings have 3.1 certificates.
Advantages: the pipe does not require beveling for welding. Socket Weld fittings do not require special preparation, and are an alternative to threaded fittings.
Disadvantages: not recommended for radioactive installations.
Steel grade 316 / 316L - is a very popular stainless steel with high corrosion resistance. It has excellent welding and forming properties. It is qualitatively superior to steel grade 304.
Another name for grade 316: DIN 1.4401 1.4404 SS 316 AISI316 AISI316L SS316 SS316L.
Applications: socket fittings, socket elbows, tees, reductions, flanges, pipes, rods, plates, flats, valves, bottoms, heat exchangers, pharmaceutical equipment, dairy equipment, brewing industry, marine fittings, coastal architecture, food industry.
More information about socket weld fittings you will find here>>
Our offer includes a wide range socket weld high-pressure fittings. If you have any questions contact us. Call 63/2614202 or send an inquiry to email: biuro@polberis.pl
Write to us if you have European VAT number and do not want to pay the TAX. We will prepare an offer without VAT. Contact us if you want to know price of shipping. Send an inquiry to e-mail: biuro@polberis.pl
