Reducing Bushing 1 1/2'' × 3/4'' 316L Class 3000

Availability: last items

Dispatched within: 24 hours

Gross price: €37.56

incl. 23% TAX, excl. shipping costs

Regular price:

37.56

Net price: €30.54

excl. 23% TAX, excl. shipping costs

Regular price:

quantity pcs

product unavailable

add to wish list

Vendor:

Product code: 13392B

Description

Reducing Bushing 1 1/2'' × 3/4'' 316L Class 3000

Size: 1 1/2'' × 3/4''
Female thread: 3/4'' (thread diameter: 24.1–24.5 mm)
Male thread: 1 1/2'' (thread diameter: 47.4–47.8 mm)
Material: 316L stainless steel
Thread type: BSP (ISO 228 / Rp)
Maximum working pressure: 206 bar
Excellent weldability
Manufactured according to: ISO 228 / Rp
3.1 material certificate available on request (free of charge)
Applications: industrial installations, central heating systems, agricultural machinery, boilers, ships, heavy industry

Alternative Name: Reducing Bushing 1 1/2'' × 3/4'' 316L Class 3000, hex reducing bushing, BSP threaded reducer, stainless steel reducer, inox threaded adapter, male × female adapter, threaded bushing.

Information

Reducing Bushing 1 1/2'' × 3/4'' 316L Class 3000 is a hexagonal threaded reducing fitting designed to connect piping with different BSP thread sizes. It is suitable for high-pressure industrial systems operating up to 206 bar.

316 / 316L Stainless Steel

316 / 316L stainless steel is a highly corrosion-resistant austenitic stainless steel with excellent welding and forming properties. Compared with 304 stainless steel, it offers superior resistance to aggressive chemicals, seawater, and corrosive environments.

Equivalent grades: DIN 1.4401, 1.4404, SS316, SS316L, AISI 316, AISI 316L.

Advantages of 316 / 316L Stainless Steel

Non-magnetic
Excellent ductility
Excellent impact toughness
Outstanding weldability
Good mechanical strength
Wide operating temperature range

Applications

Heat exchangers
Pharmaceutical equipment
Dairy processing equipment
Brewing industry
Marine fittings
Coastal structures
Food processing industry
Industrial process piping

We also offer reducing bushings in other sizes. If you have any questions, please contact us. Call +48 63 261 42 02 or send your enquiry to biuro@polberis.pl.

Reducing Bushing 1 1/2'' × 3/4'' 316L Class 3000 is also available in other sizes from our product range.

Learn more about reducing bushings here >>
