Reducer bush 1''x1/2'' BSP 304L Hex
Regular price:
Regular price:
product unavailable
add to wish list
Description
Reducer bush 1''x1/2'' BSP 304L Hex
- size: 1'' - 1/2''
- external thread 1'' (thread diameter is 33 ÷ 33.2mm)
- internal thread 1/2'' (thread diameter is 18.6 ÷ 19mm)
- material: stainless steel 304L (1.4301)
- threads: BSP
- pressure class: 3000lbs
- steel excellent for welding
- on request certificate 3.1 (free of charge)
- application: pressure installations, boilers, ships, heavy industry, installations with high requirements
- origin: European Union
Other name: Reducer bush 1''x1/2'' BSP 304L Hex fitting nipple threaded bush bushing BSP MF FM A182 304L cl.3000 conical high-pressure reducer A182/A 182m-17 F304L F/M
Information
Reducer bush 1''x1/2'' BSP 304L Hex - it belongs to a group of threaded fittings “high-pressure couplings”. The reducer bushings are available in all inch sizes. Each fitting is stamped with size, grade, melt and pressure rating. They ensure safety and durability of the system. All threaded fittings have 3.1 certificates.
Grade 304 / 304L - is a standard stainless steel (SS 304L). The most versatile and widely used stainless steel, available in a wide range of products, undoubtedly has excellent forming and welding properties.
Other name: 1.4301 1.4306 1.4307 AISI304L
Advantages of 304 / 304L grade: non-magnetic steel, excellent ductility, excellent impact strength, excellent weldability, good strength, wide operating temperature range.
Application: heat exchangers, pharmaceutical equipment, dairy, brewing industry, marine fittings, coastal architecture, food industry.
You can find how to measure a thread HERE>>
More information about bushings and reductions you may find here >>
Our offer includes also bushings and reductions in other sizes. If you have any questions contact us. Call 63/2614202 or send an inquiry to email: biuro@polberis.pl
Write to us if you have European VAT number and do not want to pay the TAX. We will prepare an offer without VAT. Contact us if you want to know price of shipping. Send an inquiry to e-mail: biuro@polberis.pl
