Hamburg Elbow 26.9 x 2.6 mm P265GH Carbon Steel
Regular price:
Regular price:
product unavailable
add to wish list
Description
Hamburg Elbow 26.9 x 2.6 mm P265GH Carbon Steel
- Outside diameter: 26.9 mm
- Wall thickness: 2.6 mm
- Material grade: P265GH steel
- Manufactured according to: DIN 2605
- Seamless elbow
- Radius: 3D
- Black steel for welding
- Precision manufactured
- 3.1 material certificate available on request (free of charge)
- Applications: industry, agriculture, construction, handrails
Alternative Name: Hamburg Elbow 26.9 x 2.6 mm P265GH Carbon Steel, black carbon steel weld elbow, DIN 2605 elbow, seamless elbow, 3D elbow, carbon steel elbow, S235GH elbow, P235GH elbow, 3/4'' elbow, DN20 elbow.
Information
Hamburg Elbow 26.9 x 2.6 mm P265GH Carbon Steel is manufactured from P265GH carbon steel.
P265GH carbon steel is primarily a weldable steel grade suitable for operation at elevated temperatures. It is widely used in the petrochemical, chemical, and oil & gas industries. It is used for pressure vessels, boiler vessels, and pipes transporting hot liquids. It is a standard European steel grade.
Advantages of P265GH steel: good weldability, good cold and hot forming properties.
We also offer Hamburg elbows in other sizes. If you have any questions, please contact us. Call +48 63 261 42 02 or send your enquiry to biuro@polberis.pl.
Hamburg Elbow 26.9 x 2.6 mm P265GH Carbon Steel is also available in other sizes from our product range.
Learn more about weld fittings here >>
Technical data
| Bend Angle | 90 Degrees |
| Radius | 3D |
| Steel Grade | P265GH ~ P285GH |
| Material | Carbon Steel |
| Size | DN20 ~ 3/4'' ~ 26,9mm |
