Gasket KLINGERSIL C-4500 DN32 PN10–16 × 2 mm

Availability: last items

Dispatched within: 24 hours

Gross price: €2.55

incl. 23% TAX, excl. shipping costs

Regular price:

2.55

Net price: €2.07

excl. 23% TAX, excl. shipping costs

Regular price:

quantity pcs

product unavailable

add to wish list

Vendor:

Product code: 11605B

Description

Gasket KLINGERSIL C-4500 DN32 PN10–16 × 2 mm

Size: DN32
Thickness: 2 mm
Pressure rating: PN10–16
Material: KLINGERSIL C-4500
Applications: industrial installations, steam systems, high-pressure installations
High compression resistance

Information

About the KLINGERSIL C-4500 DN32 PN10–16 Gasket

KLINGERSIL C-4500 is a high-performance gasket material designed for chemical industry applications involving high temperatures and high pressures.

Recommended media

Recommended for: high-temperature alkaline media, superheated (unsaturated) steam, methanol, ammonia, benzene, gasoline, wet chlorine, ethane, ethylene, Freon 12, Freon 22, ethylene glycol.

Do not use with: aniline, cyclohexane, phenol, nitric acid (20%).

Test under operating conditions before use with: acetone, dry chlorine, chloroform, nitric acid.

Standard sheet sizes

Sheet sizes: 1000 × 1500 mm, 2000 × 1500 mm
Thicknesses: 0.5 mm, 1.0 mm, 1.5 mm, 2.0 mm, 3.0 mm
Manufactured according to: DIN 2690 / DIN EN 1514-1
Fire-resistant gasket sheet
Low-adhesion surface

Custom gasket cutting

Available according to:

EN 1514-1
EN 12560-1
ASME B16.20
DIN 2690
Customer technical drawings
TG flat gaskets for tongue-and-groove flanges (PN-86/H-74374/03)
SR flat gaskets for male-and-female flanges (PN-86/H-74374/04)
IBC flat gaskets for raised-face flanges (PN-86/H-74374/02)
Full dimensional range, including custom shapes
Large segmented gaskets (puzzle type)
Lead time: 2–5 days

How to install the gasket

Check that the gasket is the correct size and material.
Inspect the gasket for damage.
Check that the flanges are not distorted.
Clean the flange faces and fastening components (bolts, nuts, and washers).
Align the flanges and bolt holes.
Carefully insert and centre the gasket between the flanges.
Do not use sealing compounds.
Tighten the flanges, ensuring that the gasket is not over-compressed or damaged.

If you are unsure which gasket to choose, please contact us. Call +48 63 261 42 02 for technical advice.

We offer a wide range of gaskets and O-rings. If you are looking for a different material or size that is not listed in our store, please contact us. Email: biuro@polberis.pl, Tel: +48 63 261 42 02. We will prepare a quotation for you.

Learn more about gaskets here >>
