Gasket DN15 PN16 3mm EPDM

Availability: last items

Dispatched within: 24 hours

Gross price: €1.68

incl. 23% TAX, excl. shipping costs

Regular price:

1.68

Net price: €1.36

excl. 23% TAX, excl. shipping costs

Regular price:

quantity pcs

product unavailable

add to wish list

Vendor:

Product code: 10740EV

Description

Gasket DN15 PN16 3mm EPDM

Specifications:

Size: DN15
Thickness: 3 mm
Pressure Rating: PN16
Material: EPDM
Operating Temperature: –40 °C to +110 °C
Properties: Resistant to ozone, UV radiation, many chemical interactions, and water exposure.
Applications: Used in the production of products for the automotive industry: door and window seals, damping elements, and construction. Frequently utilized in the manufacturing of inter-flange seals, hydraulic hoses, cable covers, and roofing materials.

Another name: Gasket DN15 PN16 3mm EPDM sealing plate, weather-resistant gasket thickness gasket for flange

Information about the gasket DN15 PN16 3mm EPDM

The DN15 PN16 3mm EPDM gasket – a weather-resistant plate.

Operating temperature: –40°C to +110°C
Properties: ozone-resistant, UV radiation-resistant, resistant to various chemical interactions, water-resistant.
Applications: in the production of automotive industry products: door and window seals, cushioning elements, and construction. Used in the production of flange gaskets, hydraulic hoses, cable protection, and roofing.

How to install the EPDM gasket:

Check if the gasket is the correct size and made of the appropriate material.
Check for any damage to the gasket.
Check if the flanges are not warped.
Remove any debris from the surfaces of the flanges and mounting elements, such as bolts, nuts, and washers.
Align the flanges and bolt holes in a straight line.
Carefully insert the gasket between the flanges. Center the gasket between the flanges.
Do not use sealing compounds.
Join the flanges, ensuring that the gasket is not overly compressed or damaged.

Not sure how to choose the right seal? Call us for a consultation at 0048632614202.

You can find more about gaskets here>>

We offer a wide range of seals and O-rings. Contact us if you are looking for a seal of a different type or size. Our email: biuro@polberis.pl, phone: 0048632614202. We will prepare an offer for you.

Technical data

Size	DN15 ~ 1/2''
