Spiral Wound Gasket DN65 PN100/160 EN 1514-2 316L

• Size: DN65

• Pressure rating: PN100/160

• Type: Spiral Wound Gasket (SG/IR)

• Outer ring: Carbon steel ST37.0

• Inner ring: 316L stainless steel (SS316L)

• Winding strip: 316L stainless steel (SS316L)

• Filler material: Flexible graphite

• Spiral wound gasket with inner and outer centring rings

• Manufactured according to: EN 1514-2

• Operating temperature: -100°C to +450°C

• Suitable for flat face flanges

• Blowout-resistant

• Non-combustible

Alternative Name: Spiral Wound Gasket DN65 PN100/160 EN 1514-2 316L, SWG gasket, graphite spiral wound gasket, stainless steel flange gasket, 316L spiral gasket, SG/IR gasket, industrial flange sealing gasket.

Information

Spiral Wound Gasket DN65 PN100/160 EN 1514-2 316L is a high-performance sealing solution designed for high-pressure and high-temperature flange connections. It features a 316L stainless steel winding and inner ring, a flexible graphite filler, and a carbon steel outer centring ring, providing excellent sealing reliability under demanding operating conditions.

The gasket is manufactured in accordance with EN 1514-2 and is recommended for flat face flanges. Its spiral wound construction offers excellent resilience, pressure resistance, and long service life.

Materials

• Outer centring ring: ST37.0 carbon steel

• Inner ring: 316L stainless steel

• Winding strip: 316L stainless steel

• Filler: Flexible graphite

Advantages

• Excellent sealing performance under high pressure

• Suitable for temperatures from -100°C to +450°C

• Blowout-resistant construction

• Non-combustible

• Excellent resistance to thermal cycling

• Long service life

• Suitable for demanding industrial applications

Applications

• Petrochemical plants

• Oil refineries

• Chemical processing plants

• Power generation facilities

• High-pressure piping systems

• Steam installations

• Oil and gas industry

• Industrial flange connections

Available Standards

We offer spiral wound gaskets manufactured according to:

• EN 1514-2

• ASME B16.20 for ASME B16.5 flanges

• ASME B16.20 for ASME B16.47 Series A flanges

• ASME B16.20 for ASME B16.47 Series B flanges

We also offer a wide range of industrial gaskets and O-rings. If you require a different material, standard, or size, please contact us. Call +48 63 261 42 02 or email biuro@polberis.pl.
