Coupling 4" Socket Weld A105 Class 3000
Regular price:
Regular price:
product unavailable
add to wish list
![Pin It](http://pinterest.com/pin/create/button/?url=https://sklep.polberis.pl/en_US/p/Coupling-4-Socket-Weld-A105-Class-3000/14212&media=//sklep.polberis.pl/userdata/public/gfx/28444/Mufa-2-12-socket-weld-A105-kl.3000.jpg&description=Coupling 4" Socket Weld A105 Class 3000 "Pin It")
Description
Coupling 4" Socket Weld A105 Class 3000
- size: 4"
- pressure class: 3000 lbs (206 bar)
- socket weld fitting manufactured according to ANSI B16.11
- material: A105 (boiler carbon steel for welding, equivalent to P245GH, P285GH)
- socket weld coupling
- steel suitable for welding
- application: boilers, high-pressure systems, industrial installations, refineries, marine industry, metallurgy
- 3.1 certificate available on request (free of charge)
- origin: European Union
B = 4''
Alternative Name: Coupling 4" Socket Weld A105 Class 3000 SW High Pressure Socket Weld Fitting ANSI B16.11 Boiler Steel P245GH P285GH
Information
Coupling 4" Socket Weld A105 Class 3000 belongs to the group of high-pressure fittings, where the pipe is welded into the socket (recess). The socket welded to the pipe creates a leak-tight piping structure. The Socket Weld (SW) system guarantees safety, durability and a permanent connection. Thanks to SW fittings, the required pressure class can be easily selected. Each fitting is marked with the size, material grade, heat number and pressure class. All SW fittings are supplied with 3.1 certificates.
Advantages: the pipe does not require beveling before welding. Socket Weld fittings do not require special preparation and are an alternative to threaded fittings.
Marking: each fitting is marked with the size, material grade, heat number and pressure class. In some cases, the thread type is also marked (manufacturing and marking comply with applicable standards).
A105 steel is a carbon steel widely used for piping components and fittings such as 3/4" Socket Weld SW Couplings A105 Class 3000. This carbon steel grade is used in pressure installations operating at ambient and elevated temperatures. It offers good machinability, as with other low-alloy steels. A105 is also a weldable steel.
Application: used for oil and gas transmission, petrochemical plants, power stations, pressure vessels, etc.
Similar material grades: 1.0460, C22.8, P245GH, P265GH, P285GH.
More information you will find here >>
Our offer includes a wide range socket weld high-pressure fittings. If you have any questions contact us. Call 63/2614202 or send an inquiry to email: biuro@polberis.pl
Write to us if you have European VAT number and do not want to pay the TAX. We will prepare an offer without VAT. Contact us if you want to know price of shipping. Send an inquiry to e-mail: biuro@polberis.pl
Technical data
| Coupling Type | Coupling |
| Material | Carbon Steel |
| Pressure | Pressure Range 101–250 bar |
| Connection 1 | 2 1/2'' |
| Thread Type – Connection 1 | BSP / G / Rp / Rc Thread |
| Connection 2 | 2 1/2'' |
| Thread Type – Connection 2 | BSP / G / Rp / Rc Thread |
