Coupling 1 1/2" x 1/2" galvanized cast iron

• Size: 1 1/2'' x 1/2''
• Thread Type: Internal threads (BSP / Rp)
• Material: Ductile cast iron
• Surface Finish: Galvanized
• Standards: EN10242, N3 / 240 / M2red
• Application: Hydraulic systems, industrial installations, central heating, water pipelines

Also Known As: Reducing coupling, iron threaded adapter, galvanized ductile iron reducer, internal thread water fitting

 Information

The Coupling 1 1/2'' x 1/2'' galvanized cast iron is a reducing fitting used to connect pipes of different diameters. It is widely used in industrial and central heating systems due to its affordability and availability.

The fitting is made from ductile cast iron, providing strength and durability. Its surface is protected with hot-dip galvanizing, which prevents corrosion and increases resistance to weather conditions.

Technical Properties:

• Maximum operating pressure: 25 bar
• Operating temperature: -20°C to 120°C (for standard use), up to 300°C in specific conditions
• Threading: External tapered R thread, internal cylindrical Rp thread per ISO 7/1
• Marking: Size clearly stamped on the fitting

Available Sizes:
1/8'' – 1/4'' – 3/8'' – 1/2'' – 3/4'' – 1'' – 1 1/4'' – 1 1/2'' – 2'' – 2 1/2'' – 3'' – 4''
Note: Galvanized cast iron fittings are not available in metric sizes.

Fitting Types in the Range:
Elbows, reducing elbows, tees, reducing tees, reducers, short bends, long bends, couplings, reducing couplings, blind flanges, plugs with or without flange, T9 plugs, internal thread unions, nipple unions, gasket unions, tapered unions, straight nipples, reducing nipples.

Variants: Non-galvanized ductile cast iron fittings are also available.
